NEW Charging Type Off Grid 1000W Pure Sine Wave Inverter Power Invertor Solar Inverter

Product Categories

YUEQING RENHE ELECTRIC CO., LTD.

Contact Now

Add to Cart

Products Specification:
Model	CS12P1000-1C	CS12P1000-2C	CS24P1000-1C	CS24P1000-2C	CS48P1000-1C	CS48P1000-2C
Rated Power	1000W
Surge Power	2000W
Input Voltage	12VDC		24VDC		48VDC
Output Voltage	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%
Switching mode	City power priority
Switching time	≤10ms
Charging current	20A		10A		5A
Charging mode	Three stage charging mode
Input voltage range	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%
USB Port	5V 1000MA
Frequency	50HZ±3 or 60HZ±3
Output Waveform	Pure sine wave
Soft Start	YES
THD/AC Regulation	THD<3%(Linear Load)
Output Effciency	94.2% MAX
No Load Current	0.8A	0.8A	0.4A	0.4A	0.2A	0.2A
DC Voltage Range	10V-15.5V	10V-15.5V	21.5V-28V	21.5V-28V	41.5V-59.5V	41.5V-59.5V
Low Voltage Alarm	10.5±0.5V		21±0.5V		42±1V
low Voltage Shut Down	10±0.5V		20±0.5V		40±1V
Low Voltage Recovery	13±0.5V		24±0.5V		48±1V
Over Voltage Shut Down	15.5±0.5V		31±0.5V		61±1V
Over Voltage Recovery	14.8±0.5V		29±0.5V		59±1V
Cooling Way	Intelligent Cooling Fan
Protection	Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit
Working Temperature	(-10℃+60℃ Civil class,-25℃+60℃ technical grade,-40℃+70℃ army grade)
Storage Temperature	(-30℃ - 70℃)
Humidity	90% MAX,Non-condensing
Warranty	2 Years
Net Dimension	40016590MM(LxWxH)
Package Dimension	535220140MM(LxWxH)
N.W./Unit/G.W./Unit	3.62kg/4.06Kg
Ctn	4PCS
Meas./Ctn	550475315mm(LxWxH)
G.W./Ctn	17.26kg

NEW Charging Type Off Grid 1000W Pure Sine Wave Inverter Power Invertor Solar Inverter
