6000 Watt Multifunction off grid pure solar inverter with power

Product Categories

YUEQING RENHE ELECTRIC CO., LTD.

Contact Now

Add to Cart

Products Specification:
Model	CS12P6000-1	CS12P6000-2	CS24P6000-1	CS24P6000-2	CS48P6000-1	CS48P6000-2
Rated Power	6000W
Surge Power	12000W
Input Voltage	12VDC		24VDC		48VDC
Output Voltage	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%
USB Port	5V 1000MA
Frequency	50HZ±3 or 60HZ±3
Output Waveform	Pure sine wave
Soft Start	YES
THD/AC Regulation	THD<3%(Linear Load)
Output Effciency	94.2% MAX
No Load Current	2.8A	2.8A	1.4A	1.4A	0.8A	0.8A
DC Voltage Range	10V-15.5V	10V-15.5V	21.5V-28V	21.5V-28V	41.5V-59.5V	41.5V-59.5V
Low Voltage Alarm	10.5±0.5V		21±0.5V		42±1V
low Voltage Shut Down	10±0.5V		20±0.5V		40±1V
Low Voltage Recovery	13±0.5V		24±0.5V		48±1V
Over Voltage Shut Down	15.5±0.5V		31±0.5V		61±1V
Over Voltage Recovery	14.8±0.5V		29±0.5V		59±1V
Cooling Way	Intelligent Cooling Fan
Protection	Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit
Working Temperature	(-10℃+60℃ Civil class,-25℃+60℃ technical grade,-40℃+70℃ army grade)
Storage Temperature	(-30℃ - 70℃)
Humidity	90% MAX,Non-condensing
Warranty	2 Years
Net Dimension	610200150MM(LxWxH)
Package Dimension	735308240MM(LxWxH)
N.W./Unit/G.W./Unit	11.62kg/13.44Kg
Ctn	1PCS
Meas./Ctn	735308240mm(LxWxH)
G.W./Ctn	13.44kg

6000 Watt Multifunction off grid pure solar inverter with power
